12"-18" Pipe Bevelling Machine , Industrial Pipe Cutting Tools

Name: 12quot18quot Pipe Bevelling Machine Industrial Pipe Cutting Tools
Brand: NODHA
Price: 1 USD

Quality 12"-18" Pipe Bevelling Machine , Industrial Pipe Cutting Tools for sale

Brand Name : NODHA

Model Number : AODE-457

Certification : CE,ISO

Place of Origin : WUXI

MOQ : 1 SET

Price : Negotiation

Payment Terms : L/C, T/T, Western Union

Supply Ability : 500 SETS/ YEAR

Delivery Time : 5-7 Working Days

Packaging Details : Shrink-wrapped machine body inside, exporting plywood case outside, one set each plywood case.

Name : cold pipe cutting and beveling machine

Drive : Electric Driven

Power : 1600-2400W

Working Range(OD) : 12"-18"(300-457mm)

Wall Thickness : ≤30

Mounting Method : Split OD Mount

Working Weight : 65.5kgs

Shipping Weight : 106.5kgs

Package Size : 920*870*280mm

Meterial : Aluminum

Voltage : 220-240V

Frequency : 50/60HZ

Contact Now

Pipe Cutting and beveling Machine

The series machine is ideal for all types of pipe cutting & beveling and end preparation. The split frame design allows the machine to split in half at the frame and mount around the OD of the in-line pipe or fitting for strong, stable clamping. The equipment performs precision in-line cut or simultaneous cut/bevel, single point, counterbore and flange facing operations, as well as weld end preparation on open ended pipe, Working Range from 2” to 48” O.D.(DN50-1200), on most wall thicknesses and material.

Features of cold pipe cutting and beveling machine

Cold Cutting & Beveling improve safety
Cutting and Beveling at the same time
Self-acting tools feed
Minimal Axial and Radial clearance
Light weight and Compact design
Easy installation & Operation
Pneumatic or Electric or Hydraulic driven
Machining heavy-wall pipe from 2” up to 48”

Application of cold pipe cutting and beveling machine

Oil & Gas File
Power & Chemical Plant
Nuclear Power Plant
Process Plant & Fabrication
Ship Building And Repair

Specification of cold pipe cutting and beveling machine

Drive Options: Pneumatic, Hydraulic, and Electric
Air requirement: 1500L-3000L /Min@0.6/0.7Mpa
Hydraulic requirement: 2-60L per minute 12.5Mpa
Electric requirement:220-240V 1PH 50/60HZ
Feed mode: Star wheel, automatically
Feed rate: Fixed 0.08mm per circle

Selection Guide

12"-18" Pipe Bevelling Machine , Industrial Pipe Cutting Tools

Model	Working Range (OD)		d (mm)	D(mm)	L (mm)
Model	Inch	mm	d (mm)	D(mm)	L (mm)
168	2”-6”	50-168	185	512	178
230	3”-8”	80-230	236	564	178
275	5”-10”	125-275	283	612	178
325	6”-12”	168-325	334	665	178
377	8”-14”	219-377	386	719	178
426	10”-16”	273-426	438	776	180
457	12”-18”	300-457	469	807	180
508	14”-20”	355-508	518	862	190
560	16”-22”	400-560	570	910	190
610	18”-24”	457-610	618	960	190
660	20”-26”	508-660	670	1020	190
715	22”-28”	550-715	719	1084	190
762	24”-30”	600-762	770	1134	190
830	26”-32”	660-813	830	1194	192
914	30”-36”	762-914	924	1296	212
1066	36”-42”	914-1066	1077	1468	212
1230	42”-48”	1066-1230	1248	1646	212

Suggest: size 1066 and above size select and use hydraulic type

Order Guide

Before you place order to us, please let us know the following information:

Choose suitable Model
Confirm electric power supply ( Voltage, frequency and phase)
Confirm the beveling angel needed
Confirm the welding joint required (U, V, Double V or Compound preparation)
Advise your pipe material ( Carbon steel, stainless steel or others)
Other special demands about machine
If the pipe wall thickness more than 30mm, inform us in advance (Important)

Working On Site

12"-18" Pipe Bevelling Machine , Industrial Pipe Cutting Tools

Exhibition

12"-18" Pipe Bevelling Machine , Industrial Pipe Cutting Tools

Certification

12"-18" Pipe Bevelling Machine , Industrial Pipe Cutting Tools

After-Sale Service

1. Warranty period: 12 months

2. Emergency spare parts required dispatched within 24 hours
